StarTech ET91000SFP2C Gigabit Ethernet Fiber Media Converter Card Module With Open SFP Slot

StarTech ET91000SFP2C Gigabit Ethernet Fiber Media Converter Card Module With Open SFP Slot - Image 2

StarTech ET91000SFP2C Gigabit Ethernet Fiber Media Converter Card Module With Open SFP Slot - Image 3

StarTech ET91000SFP2C Gigabit Ethernet Fiber Media Converter Card Module With Open SFP Slot

Original price was: $122.05.Current price is: $85.44.

SKU: BWFYA 28064261 Category: Ethernet Over Fiber Extenders

Efficient and effective customer service, online.
Your needs, our top priority.
No-Questions-Asked Returns
High quality products, low prices.

Description
Reviews (0)

ET91000SFP2C – Overview

The ET91000SFP2C Open SFP Fiber Media Converter card module converts and extends a Gigabit Ethernet connection over fiber, using the Gigabit SFP of your choice. A versatile solution for connecting an Ethernet (1000Base-T) network to remote network segments over a fiber backbone, the media converter features an open SFP slot that lets you choose the MSA-Compliant Gigabit SFP that best suits your fiber connection mode (single / multi-mode) and distance requirements (see our full line of Gigabit transceivers for compatible solutions). Designed for applications where multiple chassis-powered media converters are required, this Gigabit media converter ships as a card module that can easily be installed into the 20 Slot, 2U Rackmount Chassis (ETCHS2U). For standalone operation this Gigabit media converter can also be purchased as a standard Open SFP Media Converter (ET91000SFP2). The fiber to Ethernet converter offers simple plug-and-play installation, while support for full-duplex operation and Jumbo Frame support provides efficient network operation. Backed by a StarTech.com 2-year warranty and free lifetime technical support.

Features:
- Media Converter card module designed for installation into the ETCHS2U Rackmount Chassis
- Open SFP slot supports MSA-Compliant Single / Multi-Mode Gigabit SFPs at varying distances
- Advanced features include Link-loss forwarding, remote monitor status, two frame lengths
- Supports full or half-duplex operation
- Easy to use and install
- Jumbo Frame support
Specifications:
- Hardware
- Chipset ID: Marvell – 88E1111
- Industry Standards: IEEE 802.3ab 1000BASE-T, IEEE 802.3u 100BASE-LX, IEEE 802.3z 1000BASE-SX
- PoE: No
- WDM: No
  Performance
- Auto MDIX: Yes
- Fiber Operating Mode: Half/Full-Duplex
- Maximum Data Transfer Rate: 1.25 Gbps
- MTBF: 65, 000 Hours
  Connector(s)
- Local Unit Connectors: 1 – RJ-45 Female, 1 – SFP Slot Female
  Special Notes/Requirements
- Note: Fiber data transfer speeds and distances are dependent on the SFP used (sold separately)
  Power
- Center Tip Polarity: Positive
- Input Current: 1 A
- Input Voltage: 12 DC
- Plug Type: M
- Power Consumption (In Watts): 8W
- Power Source: Not Included (not required for standard applications)
  Environmental
- Humidity: 10~90% RH (Non-Condensing)
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -10°C to 70°C (14°F to 158°F)
  Physical Characteristics
- Product Height: 0.8 in [21 mm]
- Product Length: 5.6 in [142 mm]
- Product Weight: 3.5 oz [100 g]
- Product Width: 2.9 in [74 mm]
  Packaging Information
- Shipping (Package) Weight: 5.3 oz [150 g]
Item Includes:
- 1 – Fiber Media Converter
- 1 – Instruction Manual
Warranty:
- 2 Years
GTIN:

0065030852524
